Series
E7K Series
Type
4K Ultra HD
Size
43" | 55" | 65" | 75"
Colour

(Bezel, Rear, Stand)
Grey / Black / Grey


Resolution
3840 x 2160
Colour Depth
8 bit+FRC
Refresh Rate
60Hz VRR
Motion Rate
120 Smooth Motion
Brightness
43" - 300 cd/m² Typical

55", 65", 75" - 350 cd/m² Typical
Contrast Ratio
43", 55" - 4000:1

65", 75" - 1300:1
HDR System
Dolby Vision, HDR 10, HLG
MEMC
Yes
Eye Care
TUV Cert. - Low Blue Light
Others
VRR, ALLM, Backlight Control
Engine
Hi-View Engine - 4K UHD AI Upscaler, AI Picture
Picture Mode
Dynamic, Standard, Natural, Game, Sports, Cinema, Calibrated, FILMMAKER MODE


Audio

Audio Enhancement
Dolby Atmos, DTS Virtual X
Speaker
43", 55", 65" - 12W x 2 Midrange

75" - 18W x 2 Midrange
Others
Automatic Volume Level (AVL), Audio Equalizer
Sound Mode
Standard, Theatre, Sports, Music, Speech, Late Night


Smart TV

User Interface
Google TV
Screen Mirror
Chromecast, Apple Airplay, Miracast, DLNA
Voice Command
Google Assistant, Far Field Voice Control
Installed App
Netflix, Disney+, Youtube, Prime Video & others
Advance Mode
Game Mode, Sports Mode
Others
Web Browser, Personal Video Recorder,Phone Remote
Phone Remote
Yes, Google App


Connectivity

WiFi
2.4 & 5.0 GHz
Bluetooth
Bluetooth 5.0
HDMI
HDMI 2.0 (4K @ 60Hz) x 3
HDMI ARC
HDMI eARC x 1
USB
USB 2.0 x 2
Others Port
Ethernet Port, Antenna, AV Input, SPDIF, Earphone Jack, Digital Audio Out


Features

On/ Off Timer
Yes
Power Off
Yes (If No Signal)
Sleep Timer
Yes
Hotel Lock
Yes
Program Lock
Yes
Others
Software Ver. OSD Indication, Legal requirements: Disclaimer / Acceptance of Terms, Favourite Channel List, Electronic Point Of Sales (E-POS), OTA - Over Air Software Updates


USB Media Player

PVR
Yes, Personal Video Recorder
Time Shift
Yes
DTV Recording
Yes,  EPG scheduling / Start from Standby
Decoder
MPEG4 (H.264) / H.265
DMP Content
Music / Video / Photos
DMP
Yes, for UHD content via USB
DMP & PVR
FAT32 / NTFS


Hardware

Processer/ Cores
4K Processor / Quad Core
Supply Range
100 ~ 240V Voltage , 50Hz/60 Hz Frequency
Standby Consumption
< 0.5W


Installation

With Stand

(W x H x D)
43" - 963 × 614 × 238mm / 7.4 kg

55" - 1232 × 752 × 298 mm / 11.5 kg

65" - 1452 × 896 × 300 mm / 16.7 kg

75" - 1676 x 1004 x 380 mm / 22.5 kg
Without Stand

(W x H x D)
43" - 963 × 566 × 74 mm / 7.3 kg

55" - 1232 × 711 × 74 mm / 11.3 kg

65" - 1452 × 834 × 74 mm / 16.5 kg

75" - 1676 x 966 x 87 mm / 22.2 kg
Package

(W x H x D)
43" - 1088 × 132 × 654 mm / 9.7 kg

55" - 11364 × 142 × 827 mm / 17.5 kg

65" - 1602 × 160 × 996 mm / 24.5 kg

75" - 1865 x 210 x 1146 mm / 32 kg
Stand Area

(W x D)
43" - 765 x 238 mm

55" - 921 × 298 mm

65" - 1168 × 300 mm

75" - 1316 x 380mm
Wall Mount

(H x V)

VESA Compliance

43" & 55" - 200 x 300 mm

65" & 75" - 400 x 300 mm
Wall Mount Screw
M6
Detachable

Power Cord
155 cm
Accessories
TV Stand, Bluetooth Remote, AAA x 2, User Manual, Quick Setup Guide, Power Cable
